528 Ton, 65.82 oz., Haitian MA II 4700/2950 Injection Molding Machine (2016)
528 Ton, 65.82 oz., Haitian MA II 4700/2950 Injection Molding Machine (2016)
Available quantity:1
orCall +1 508-792-4305
Description
Air Blast, Core Pull, Robot Interface
33,949 hours as of 11-22
Specifications
| Manufacturer | Haitian |
| Model | MA II 4700/2950 |
| Year | 2016 |
| Condition | Used |
| Stock Number | 13137 |
| US Tonnage | 528 |
| Shot Size (oz. of PS) | 65.82 |
| Screw Diameter | 84 mm |
| Platen Size (in.) | 47.64 x 46.46 |
| Tiebar Spacing (HxV) in. | 32.2 x 32.2 |
| Max Mold Height (in.) | 30.71 |
| Min Mold Height (in.) | 12.60 |
| Opening Stroke (in.) | 30.71 |
| Open Daylight (in.) | 61.42 |
| Ejector Stroke (in.) | 7.87 |
| Voltage | 460V / 60HZ |
